Alloy Steel 20CrMnMo 42CrMo4 Forgings for Oilfield Equipment, Metallurgy, and Port Machinery. We supply high-quality forged alloy steel components made from 20CrMnMo and 42CrMo4, designed for use in oilfield drilling equipment, metallurgical systems, and port heavy machinery. These forgings offer excellent strength, impact resistance, and machinability, making them ideal for demanding industrial applications requiring high reliability and long service life.
Material Grades:
-
20CrMnMo – A premium alloy carburizing steel with excellent wear resistance, core strength, and fatigue performance. Widely used in heavy-duty gear and shaft applications.
-
42CrMo4 – A high-strength, tempered alloy steel with excellent toughness and hardenability. Suitable for large forged parts under dynamic loading conditions.
Available Forging Types:
-
Shafts (straight, stepped, hollow)
-
Rings and flanges
-
Gear blanks and hubs
-
Cylindrical or block-shaped forgings
-
Custom shapes per drawing
Key Features:
-
Weight range: 100KG – 7000KG
-
Forged from high-quality alloy steel ingots or bars
-
Controlled forging process ensures uniform grain structure and mechanical properties
-
Heat treated to customer specification
-
Rough or semi-finished machining available
-
Non-destructive testing: UT, MPI, and material certification provided
Applications:
-
Oil & gas equipment: drill collars, tool joints, drive shafts
-
Metallurgy: rollers, press components, structural shafts
-
Port machinery: crane shafts, winch gears, structural forgings
-
Heavy-duty transmissions and industrial gearboxes
| Product Name | Alloy Steel 20CrMnMo 42CrMo4 Forgings for Oilfield Equipment, Metallurgy, Port Machinery |
| Material | 4140,4130,18CrNiMo7-6,4340,4330,1.7225,35#
45#
20CrMnTi
20CrNi2Mo
20CrMnMo
18CrNiMo7-6
42CrMo
20CrNo
35CrMo |
| Equipment | 5 TON, 8 TON, 12 TON Hydralic hammer |
| Apply for | Oilfield Equipment, Metallurgy, Port Machinery |
| Manufacturing Process | Forging+heat treatment+rough machining |
| Forging ratio | ≥3 Presents the advantage of strengthened structural resilience, a more compact internal arrangement, and a demonstrably better performance against fatigue in complex lifting situations. |
| Delivery terms | Rough machining(N+T) |
| Test equipment | Spectrograph, UT device, tensile and impact test machine, metalloscope,external micrometer, bore dial indicator, hardness testing device and so on. |
| Service | Our integrated service covers the complete spectrum: commencing with forging, proceeding through all processing and heat treatment stages, culminating in precise final machining, followed by secure packaging, local transportation, efficient customs clearance, and reliable maritime shipment. Driven by a strong customer focus and an inherent dedication to superior product quality, we strive to exceed expectations at every touchpoint. |
The steel forgings production flow:
Raw material steel ingot into warehouse(test the chemical composition) → Cutting→ Heating(Furnace temperature test) → Heat treatment after forging(Furnace temperature test) Discharge the furnace(blank inspection)→ Machining→ Inspection(UT,MT,Visal dimension, hardness)→ QT→ Inspection(UT, mechanical properties, hardness, grain size)→ Finish machining→ Inspection (dimension)→ Packing and Marking(steel stamp, mark)→ Storage Shipment.
Frequently Asked Questions (FAQs)
-
What is the typical weight spectrum of the forged components you manufacture? Our forging capabilities encompass a range of components weighing from 100 kilograms up to 7 metric tons.
-
Do you handle downstream processing such as thermal treatment and material removal? Indeed, we provide comprehensive in-house services for heat treatment, encompassing both preliminary and final machining operations.
-
Which industrial sectors are the primary beneficiaries of your forged products? We cater to a diverse array of critical industries, including wind power generation, heavy machinery manufacturing, port infrastructure, power transmission systems, and various others.
-
What are the typical timeframes for the completion and dispatch of orders? For items readily available in our inventory, the standard lead time is approximately 30 days. For custom-manufactured orders, the timeframe generally spans 40 to 45 days.
-
Could you provide information on the geographical location of your manufacturing facility and shipping hub? Our production plant is situated in Changzhou City, strategically located near Shanghai, and we utilize the Port of Shanghai for our shipping logistics.
Request a Quotation
To receive a tailored price assessment and a comprehensive engineering solution designed to meet your specific needs, please forward your detailed technical drawings and requirements to our dedicated team. Our experienced engineers will promptly review your submission and provide you with a professional quotation and a suitable solution.
